Stamping/ Stacking Robot SDCX RMD-300/200/160/120/35/08/110/20/50 egosipụtara

Stamping/Robot Stacking SDCX RMD-300/200/160/120/35/08/110/20/50

Okwu mmeghe nkenke nke ngwaahịa

The stamping robot na-ọtụtụ ebe maka stacking, destacking, njem na ndị ọzọ ọrụ na ubi nke mbukota, ihe ọṅụṅụ, chemical ụlọ ọrụ, nri, wdg, na-enye ndị ọrụ na zuru set nke ngwa ngwa, nchekwa, mgbanwe, ziri ezi na n'ọkwa ọrụ ngwọta.

KPỌTỤRỤ ANYỊ

Nkọwa ngwaahịa

Mkpado ngwaahịa

Nka nka

Ụdị No.	Ogo nke nnwere onwe	Ụdị ịkwọ ụgbọala	Ibu ibu (KG)	Izi ezi nguzozi ugboro ugboro (mm)	Oke ngagharị (°)				Ọsọ kacha (°/s)				Ibu ike ekweghi ekwe nke nkwojiaka (kg·m²)	Okirikiri iti (okirikiri/awa)	Radius nke ngagharị (mm)	Ibu Mpaghara (kg)
Ụdị No.	Ogo nke nnwere onwe	Ụdị ịkwọ ụgbọala	Ibu ibu (KG)	Izi ezi nguzozi ugboro ugboro (mm)	J1	J2	J3	J4	J1	J2	J3	J4	Ibu ike ekweghi ekwe nke nkwojiaka (kg·m²)	Okirikiri iti (okirikiri/awa)	Radius nke ngagharị (mm)	Ibu Mpaghara (kg)
SDCX-RMD300	4	AC servo mbanye	300	±0.5	± 180	± + 100-44	± + 121-15	± 360	85	90	100	190	134	1000^③	3150	1500
SDCX-RMD200	4	AC servo mbanye	200	±0.3	± 180	± + 100-44	± + 121-15	± 360	105	107	114	242	78	1300^③	3150	1500
SDCX-RMD160	4	AC servo mbanye	160	±0.3	± 180	± + 100-44	± + 121-15	± 360	123	123	128	300	78	1500^③	3150	1500
SDCX-RMD120	4	AC servo mbanye	120	±0.3	± 180	± + 100-44	± + 121-15	± 360	128	126	135	300	78	1560^③	3150	1500
SDCX-RMD50	4	AC servo mbanye	50	±0.2	± 178	± + 90-40	± + 65-78	± 360	171	171	171	222	4.5	1700^②	2040	660
SDCX-RMD20	4	AC servo mbanye	20	±0.08	± 1170	± + 115-25	± + 70-90	± 360	170	170	185	330	0.51	1780^①	1720	256
SDCX-RMD08	4	AC servo mbanye	8	±0.08	± 170	± + 90-40	± + 68-90	± 360	251	195	195	367.5	0.25	1800^①	1433	180

Okwu:

① Usoro ule bụ 150mm dị elu na 1000mm n'obosara, na oge okirikiri na-emetụta ọnọdụ ọrụ n'ezie;

② Usoro ule ahụ dị elu 200mm na 1000mm n'obosara, na oge okirikiri na-emetụta ọnọdụ ọrụ n'ezie;

③ Usoro ule ahụ dị elu 400mm na obosara 2000mm, na oge okirikiri na-emetụta ọnọdụ ọrụ n'ezie;

Zere kọntaktị na gas na-ere ọkụ, ihe mgbawa na nke na-emebi emebi na mmiri mmiri;Mee ka a ghara ịfesa ya na mmiri, mmanụ na ájá;Wepụ na isi iyi ụda eletriki (plasma)
